PET-7H16M Ethernet High Speed DAQ Module with 8-ch AI, 4-ch DI, 4-ch DO & PoE

£439.24

Features

  • 8 Single-ended Analog Input Channels (16-bit Resolution)
  • 16-bit ADC with Built-in Anti-aliasing Filter
  • Supports Real Sample and Hold
  • Sample Rate up to 200 kS/s
  • 4 x DI & 4 x DO  Channels
  • Continuous & N Data Sample Data Transmission Mode
  • A/D Trigger Mode
  • Built-In 10/100BASE-T Auto-negotiating, Auto MDI/MDI-X Ethernet Port

Description

The ICP DAS PET-7H16M is an high speed data acquisition devices built-in a Ethernet communication port for data transfer over the network and it includes eight high speed 16-bit single-ended analog inputs (200 KHz sample and hold for 8 channels), 4-channel digital inputs and 4-channel digital outputs. It provides programmable input range on all analog channels (±5 V and ±10 V), digital output can be set output with Short-circuit protection and overload protection. The counter value of 4-channel Low-speed DI counters and 1-channel High-speed counter are latched by ADC sampling time synchronously.

The ICP DAS PET-7H16M also has qualification for 4 kV ESD protection as well as 2500 VDC intra module isolation. In addition, the 16-bit ADC includes built-in anti-aliasing filtering to adjust the appropriate sampling rate and filter out modulator and signal noise. The ICP DAS PET-7H16M is not only suitable for a wide range of mobile/portable measurement applications, but also for precision signal measurement.
