ODOT CT-7220 Power Supply Extension Module 5V/2A


Key Features

• System Power: Nominal: 24Vdc, Range: 9-36Vdc
• Protection:Overcurrent protection, anti-reverse connection protection
• Module Internal Power Consumption:20mA@5VDC
• Internal Bus Supply Current: Max: 2.0A@5VDC
• Isolation: System Power to Field Power Isolation
• Field Power:  Power Supply:22~28V(Nominal: 24Vdc)
• Field Power Supply Current:  Max. DC 8A
•Operational Temperature: -40~85℃


The ODOT CT-7220 is a power supply extension module with 5V/2A power output rating that can be integrated with the ODOT Network Adapters.

The ODOT CT-7220 can be easy integrate with SCADA, PLC, PAC and PC based software systems for a wide range of industrial automation, measurement and process control applications.
