ODOT CT-221F 16 channels digital output/24VDC/Sink type


Key Features

• Channel Number:16 channel digital output/24VDC/ Sink type
• LED Indicator: 16 output LED Indicators
• Rated current:Typical value: 500mA
• Leakage current: 10uA Max
• Output impedance:<200mΩ
• Protection Over-temperature shutdown: typical value 160℃
• Over-current protection: typical value 1.8A
• Short circuit protection support


The ODOT CT-221F is an I/O expansion module that supports 16 channels digital (sink) output with 24 VDC voltage output and can be integrated with the ODOT Network Adapters.

The ODOT CT-221F can be easy integrate with SCADA, PLC, PAC and PC based software systems for a wide range of industrial automation, measurement and process control applications.
