IPOE-175S Industrial IP67 802.3bt PoE++ Splitter (DC 12V, -40~75 degrees C)

£169.00

Add to quote

Key Features

  • Two 10/100/1000BASE-T Gigabit RJ45 ports
    • 1-port Data + Power input
    • 1-port Data output
  • One 2-pin terminal block for power output. (12V DC, 5A)
  • IP67-rated and IK10-rated aluminum case
  • LED indicators for power LED and DC Ready
  • Wall-mount design
  • Supports 6KV DC Ethernet ESD protection
  • -40 to 75 degrees C operating temperature
  • Plug and Play installation
CE FCC RoHS WEEE

Description

To fulfill the growing outdoor PoE applications, PLANET IPOE-175S is an Industrial-grade, IP67-rated 802.3bt Power over Ethernet Splitter which delivers the Ethernet digital data and PoE power from an 802.3bt PoE++ PSE (power source equipment) over a UTP cable. It enables to deliver of a maximum of 60-watt 12V DC power output to a non-PoE powered Ethernet device. Also, supports passive 10/100/1000Mbps Ethernet connection and distance up to 100 meters.

The IPOE-175S is designed to work under the operating temperature range from -40 to 75 degrees C. It’s an ideal solution to transfer power to a traditional network device with high power demand directly without the need to install additional power outlets, and electrical cabling in the industrial environment.

Quick and Easy 802.3bt PoE++ Network Deployment

If the existing network deployment consists of non-PoE powered devices that require high power to function, the IPOE-175S, powered by an 802.3 PoE++ power sourcing equipment, can feed the PDs with 802.3bt PoE++  as the splitter can split the data and power into two streams. The PDs get their power through the splitter’s DC jack and the RJ45 interface accepts only Ethernet data.

C-IPOE-175S_L
