tM-AD5 5-channel Isolated Analog Input Module


Key Features

  • 5-channel Differential Inputs
  • Voltage Inputs
  • Adjustable Sampling Rate
  • Dual Watchdog


The ICP DAS tM-AD5 is an analog input module that includes 5 differential analog input channels and provides a programmable input range on all analog inputs (±1 V, ±2.5 V, ±5 V, ±10 V). It provides high overvoltage protection of 120 VDC.

The sampling rate of the tM-AD5 is adjustable and is available in either fast or normal mode. It also provides 4 kV ESD protection as well as 2500 Vrms intra-module isolation.


• Industrial Automation
• Industrial Machinery
• Building Automation
• Food and Beverage Systems
• Semiconductor Fabrication
• Control Systems
