ODOT AIO-X3424 4-ch Analog Differential Input (0 & 4-20mA, ± 20 mA), 16-bit
£46.00
Key Features
• Number of channels: 4-ch differential current input
• Input Range: -23.5 – +23.5mA
• Resolution: 16 bit
• Input Range: -23.5 – +23.5mA
• Resolution: 16 bit
• Acquisition Accuracy: ±0.3% full scale @25℃; ±0.5% full scale @-20 – 70℃
• Sampling Frequency: 50Hz / 4 channels
• Data Format: 16-bit signed integer
Description
The ODOT AIO-X3318 is a 4-channel differential current signal acquisition with configurable 0-20mA or 4-20mA, ± 20mA input current range that is specifically designed for used with the ODOT AIOBOX-16/32 I/O system. The internal bus and field input of the module are isolated.
