ODOT AIO-X4324 4-ch Analog Output (0- 20mA or 4-20mA, 0-24mA), 16-bit


Key Features

• Number of channels: 4-ch Single-end common ground output
• Output Range: 0-20mA/4-20mA/0-24mA
• Resolution: 16 bit
• Acquisition Accuracy: ±0.3% full scale @25℃; ±0.5% full scale @-20 – 70℃
• Conversion time: 2ms / all channels
• Load: 1KΩ Max


The ODOT AIO-4324 is a 16-bit 4-ch configurable 0-20mA or 4-20mA, 0-20mA output current range that is specifically designed for used with the ODOT AIOBOX-16/32 I/O system. The internal bus and field output of the module are isolated.
