ODOT BT-3244 4-ch current input / 0&4-20mA,±20mA, 15 bit, Single-ended bipolar

ODOT BT-3244 4-ch current input / 0&4-20mA,±20mA, 15 bit, Single-ended bipolar

£53.00

Add to quote

Key Features

• Number of channels: 4-ch input
• Input Range: 0 – 23.5mA Max
• Resolution: 15 bit
• Acquisition Accuracy: ±0.3% full scale @25℃; ±0.5% full scale @-20 – 70℃
• Sampling Frequency: 50Hz / 4 channels
• Data Format: 15-bit signed integer

Description

The ODOT BT-3244 is a 4-channel current signal acquisition module with 0-20mA or 4-20mA input current range that is specifically designed for used with the ODOT BOXIO-64/32 I/O system. The internal bus and field input of the module are isolated.

B-Series-Modular-integrated-IO-User-Manual-V1.00-2021.08.30
