ODOT BOXIO-64 5 Slots I/O Expansion Module
£30.00
Key Features
• Standard voltage: 24VDC
• Voltage Range: 9-36VDC
• Power: Max.250mA@24Vdc
• Voltage Range: 9-36VDC
• Power: Max.250mA@24Vdc
• 10 wiring: Max.l.5mm2(AWG16)
• System wiring: 3.81mm plug screw terminal
• Field wiring: 3.5mm plug screw terminal
• Expansion slot supported : 5 slots
• BOX-64 supports: double-deck mother board, 5 slots, slot 0 for communication adaptor & slot 1/2/3/4 for I/O modules
Description
The ODOT BOXIO-64 is a compact size, DIN rail mounted I/O expansion module that offer users the flexibility to configure I/O system to meet a vast range of industrial monitoring and control applications.
The ODOT BOXIO-64 is equipped with a single deck motherboard and support up to 5 expansion slots.
The first slot (slot 0) of the ODOT BOXIO-64 is specifically dedicated for integrating communication protocol adapter (either Modbus (TCP/RTU)/ProfiNet/ProfibusDP/EtherCAT/CANopen) depending on the application requirement. The other slots 1/2/3/4 are used for I/O expansion.
There are a vast array of I/O modules that can monitor and control process signals such as volts, mA and temperature, or switches and digital signals; which makes the ODOT BOXIO-64 I/O system easy to integrate with SCADA, PLC, PAC and PC based software systems for a wide range of industrial automation, measurement and process control applications.
