I-9053P 16-ch Isolated DI Module


Key Features

  • 16-channel Digital Input
  • Channel Status LED Indicators
  • Compatible with 24 V Levels
  • Long Distance Measurement
  • Dry and Wet Contact, Selectable via Wire Connections
  • 3750 Vrms Intra-module Isolation
  • 4 kV ESD Protection
  •  Dual Watchdog
  • Wide Operating Temperature Range: -25 to +75 °C


The ICP DAS I-9053P offers 16 channels for digital input, catering for both dry and wet contact, with an effective distance for dry contact of up to 500 meters. All channels feature photo-couple isolation. The I-9053P provides 16 LED indicators that can be used to monitor the DI channel status. 4 kV ESD protection and 3750 Vrms intra-module isolation are also provided to enhance noise immunity capabilities in industrial environments.
