WISE-2841M-4GE Advanced Intelligent IIoT Edge Controller (Metal Case) (Support 4G Communication; Frequency Band for EMEA, Korea, Thailand, India and Taiwan)

WISE-2841M-4GE Advanced Intelligent IIoT Edge Controller (Metal Case) (Support 4G Communication; Frequency Band for EMEA, Korea, Thailand, India and Taiwan)

£1,499.00

Add to quote

Key Features

  • Runs on browsers, no extra software tool is required.
  • No more programming, Web pages provided for control logic editing.
  • IF-THEN-ELSE logic rules execution ability.
  • Support XV-board.
  • Support DCON or Modbus RTU Slave modules (Up to 32, COM3 and COM4 can connect to Max. 16 modules individually.).
  • Support Modbus TCP Slave modules (Up to 16).
  • Timer and Schedule functions supported.
  • Data logger and data files send back function supported.
  • Active I/O sending function for real-time data transfer.
  • CGI Command sending and receiving function supported for IP Camera and Network device.
  • Support Modbus TCP/RTU, FTP, MQTT and SNMP v2c/v3 protocols.
  • Support HTTPS, SFTP, FTPS encrypted communication protocols.
  • Support VPN function.
  • Support Line, Telegram, WeChat and Email real-time message sending.
    • Please note: An Enterprise WeChat account is required for WISE to send the messages to the members under the enterprise WeChat account.
  • Support Connection with IoT Cloud Platform (Amazon Web Services, Microsoft Azure and IBM Bluemix).
  • Support IoTstar Cloud Management Software.
  • Support 4G wireless data communication.

CE RoHS WEEE

Description

The Advanced IIoT Edge Controller – WISE-2841M-4GE inherits the features of the original WISE series controllers: perform system setting and monitoring by browser, powerful IF-THEN-ELSE logic operation capability, connection ability to a variety of I/O modules, support data computing and real-time message notification functions.
In order to meet the requirement of high level information security protection of the IoT(Internet of Things) system, WISE-2841M-4GE provides a variety of encrypted communication protocols as below. With the HTTPS protocol supported by WISE-2841M-4GE, users can securely access the WISE web page without worrying about the setting being stolen. Through the SNMP v3 protocol, WISE-2841M-4GE can be perfectly integrated with the IT and Network management system. Users can securely download data log files stored from WISE through SFTP and FTPS protocols.
The WISE-2841M-4GE supports the setting of blacklist and whitelist, which allows users to filter and block the specific domains. With the equipped VPN function, WISE-2841M-4GE can connect to devices in a specific secure network domain to completely isolated from the threats of information security outside.
In the integration with Cloud Platform, WISE-2841M-4GE can connect to the IoT services of Amazon Web Services, Microsoft Azure and IBM Bluemix cloud platforms. It also can integrate with the IoTstar Cloud Management software provided by ICP DAS. Based on the powerful integration capabilities with IT/IoT network environment, it make WISE-2841M-4GE series modules as the best IIoT Edge controller in the IoT Age.

WISE-2841M_APPLICATION

WISE-284xM-EN
