PCI-1002HU Universal PCI, 44 kS/s, 32-ch, 12-bit AI Multifunction Board

PCI-1002HU Universal PCI, 44 kS/s, 32-ch, 12-bit AI Multifunction Board

£399.00

Add to quote

Key Features

  • Universal PCI (3.3 V/5 V) Interface
  • Supports Card ID (SMD Switch)
  • 32 Single-ended/16 Differential Analog Input Channels
    • 12-bit, 44 kS/s AD Converter
    • Internal Pacer-trigger
  • 16-channel 5 V/TTL Digital Output
  • 16-channel 5 V/TTL Digital Input
    • Pull-high and Pull-low Resistors for DI Channels
CE UKCA FCC RoHS WEEE

Description

The ICP DAS PCI-1002HU supports 3.3 V/5 V PCI bus. These cards are a family of A/D board and features high-gain 44 kS/s AI. It provides 12-bit 32 single-ended or 16 differential AIs, 16 DI and 16 DO channels.

The PCI-1002HU provide The pull-high/ pull-low resisters allow the DI status to be specified when the DI channels are unconnected; the DI status will remain in high or low status other than floating.

The cards support various OS versions, such as Linux, DOS, Windows. DLL and Active X control together with various language sample program based on Turbo C++, Borland C++, Microsoft C++, Visual C++, Borland Delphi, Borland C++ Builder, Visual Basic, C#.NET, Visual Basic.NET and LabVIEW are provided in order to help users to quickly and easily develop their own applications.

Lead time: 5-7 working days from receipt of order.
