IXT-900-1X1UP Industrial 1-Port 10G SFP+ + 1-Port 10GBASE-T 802.3bt PoE++ Managed Media Converter

£259.00

Key Features

  • One 10G/5G/2.5G/1G/100BASE-T RJ45 interface with auto MDI/MDI-X function
  • One 10G/2.5G/1G/100BASE-X SFP+ interface
  • Supports IEEE802.3bt PoE++ standard
  • Dual 12~54VDC external power supply
  • -40 to 75°C operating temperature
  • Supports 4KVDC Contact / 8KVDC Air Ethernet ESD protection.
  • Wall-mount and DIN-rail installation
CE UKCA FCC RoHS WEEE

Description

PLANET Industrial IXT-900-1X1UP media converter is a robust network device, capable of operating in extreme temperature conditions, ranging from -40 to 75 °C. It offers 10Gbps high-speed network connectivity and media conversion between different connector types, along with advanced IEEE 802.3bt Type 4 power delivery on its copper port, which eliminates the need for separate power sources for devices like IP cameras.

This converter excels in remote management as it is equipped with secure, standalone management features suitable for both remote enterprise and telecom operations. It supports a web interface, command line interface (CLI), and SNMP for comprehensive, remote monitoring and management via PLANET CloudViewerPro and PLANET NMS.

Featuring a 10GBASE-T copper port and a 10G SFP+ port, it combines the advantages of 10G connectivity with the versatility of both fiber and copper ports. Compact yet powerful, the IXT-900-1X1UP is an ideal choice for businesses seeking to enhance their network’s speed and flexibility, making it a top choice for modern network upgrades.

The IXT-900-1X1UP can be configured to monitor the status of connected powered devices (PDs) in real time through ping action. If a PD stops working and responding, the IXT-900-1X1UP will recycle the PoE port power and bring the PD back to working condition. This greatly enhances reliability, as the assigned PoE port automatically reboots the PD, reducing the administrator’s management burden.
