EGBPU-M3210 True 4K DisplayPort HDBaseT 3.0 KVM Extender over CAT.x with Local Out, USB 2.0, Audio, Serial & 90M (PoH)

£759.00

Add to quote

Key Features

  • HDBaseT 3.0 Extension Allows Reliable Remote Access of a Computer or Video Source via a CAT.6A / 7 Cable Up to 90 Meters ( 295 feets )
  • Uncompressed True 4K DisplayPort Extension Enabled by HDBaseT 3.0 Technology
  • DisplayPort Video Supports Most Popular Resolutions Up to 4K@60Hz ( 4:4:4 )
  • HDCP Compliance (1.4 ) Ensures Proper Playback of 4K Video
  • USB 2.0 Extension Supports Keyboard, Mouse, USB Storage, USB Camera, and Other Devices
  • Serial Extension Allows for Extensive RS232 Control Applications
  • CEC Pass Through Allows Easy Control
  • Audio Embed Allows User to Insert Informative Audio Content into the DisplayPort Video
  • Audio Extract Allows Easy Connection to an Analog Audio Amplifier
  • Audio Embed Controls at Both Sides Allows Practical Audio Applications
  • PoH ( Power over HDBaseT ) Allows The Transmitter to Supply Power to The Receiver

Description

The Rextron EGBPU-M3210 DP USB Extender, 4K60@90M, Dual KVM Console, Bi-Directional Video Extension, Video Switch Splitter, Audio Embed/ Extract, USB 2.0 Hub, Serial, and PoH.

The EGBPU-M3210 is a DP USB Extender which consists of a Transmitter (Host/ PC) and a Receiver (USB Device) unit and allows you to extend DisplayPort/ HDMI, USB 2.0, 3.5mm Audio, and serial signals up to 70~100M. Based on the latest HDBaseT 3.0 technology, CAT6 DP USB Extender transmits uncompressed 720p/ 1080p/ 4K@60Hz (4:4:4) video and 480Mbps USB 2.0 signals from Tx to Rx, and vice versa.

Dedicated USB-A ports designed on the Tx and Rx of the DP USB Extender unit are suitable for both local and remote site USB peripherals access. Dual Console function allows two users (Local and Remote sides) to share one computer. The local console EGBPU-3210L enables users to access the computer directly, while the remote console EGBPU-3210R allows users to remotely control the computer as if you were sitting right in front of it.
Bi-Directional DP/HDMI signal transmission combining the Video Switch Splitter functions enables the Video output port on the Transmitter Unit (Local Out) to present local video coming from the Tx or remote video coming from the Rx, and the video signals switching can be simply achieved by button pressing. The Local Out video switching function offers a better visibility and allows local users to monitor the video signals coming from both sides, while the video splitter function broadcasts Video signal on both local (Tx) and remote (Rx) unit concurrently.
The Rextron DP USB Extender Bi-Directional Audio signal transmission combining the audio embedder/ extractor functions can independently transmit the audio signal from the Transmitter unit to the Receiver unit, and vice versa, and can arbitrarily embed audio from a 3.5mm source to the DP signal or to extract the DP audio to a 3.5mm analogue stereo audio. The diversified audio streaming functions support real-time broadcasting, on-site broadcasting, off-site broadcasting, and emergent warning.
DP USB Extender-IO

EGBPU-M3210
