DL-1052 Remote O2/CO2/Temperature/Humidity/Dew Point Data Logger with Ethernet/RS-485 and PoE

DL-1052 Remote O2/CO2/Temperature/Humidity/Dew Point Data Logger with Ethernet/RS-485 and PoE

£799.00

Add to quote

Key Features

  • Able to record PM1/2.5/10, NH3, Temperature, Humidity, and Dew Point Measurements
  • Electrochemical Sensor
  • Up to 180,000 records with date and time stamps
  • Web-based Configuration Interface
  • Simple and Powerful Software Utility, iOS APP and Android App Included
  • Supports the DCON, Modbus RTU/TCP, and MQTT Protocols
  • Includes RS-485/Ethernet/PoE Communication Interfaces
  • Relay Output for Audible/Visual Alarm or IAQ Device Control
  • Includes redundant power inputs: PoE (IEEE 802.3af, Class 1) and DC input
  • IP 43 Protection Approval
CE UKCA RoHS WEEE

Description

The ICP DAS DL-1000 can measure the concentration of particles in the air and various gas concentrations related to human health can also be measured. In addition, DL-1000 can record data and send alarm when concentration is too high.

● Particles：
Concentration of particles (PM1, PN2.5, PM10), particle count (0.3μm, 0.5μm, 1μm, 2.5μm, 5μm, 10μm)

● Concentration of various gas：
CO/ CO2/ O2/ HCHO/ TVOC/ NH3/ H2S/ SO2

The DL-1000 stores up to 180,000 downloadable records, including date and time stamps. Real-time data can be accessed from the DL-1000 series Data Logger from anywhere and at any time using the free Windows software, the iOS App or the Android App, as long as they are connected to the same local network as the Data Logger. The DL-1000 series Data Logger can be connected via widely used communication interfaces including RS-485, Ethernet and meaning that the device can be easily integrated into existing HMI or SCADA systems, and is easy to be maintained in a distributed control system. The DL-1000 series is designed for industrial applications in harsh environments that provides IP43 protection rating. The rugged RJ-45 ensures tight, robust connections, and guarantees reliable operation, even for applications that are subject to high vibration and shock.

► Multi-platform Remote Access Software

Real-time data from the DL-1000 Data Logger can be accessed from anywhere and at any time using the iAir Utility, the iOS or Android App, or via a regular web browser, as long as they are connected to the same local network as the Data Logger

► Supports the MQTT Protocol for IoT Applications


► Simple and powerful utility

The iAir Utility can be used to configure the modules, monitor real-time data, group DL-1000 modules so that the status of distribution groups can be viewed and managed. The utility also allows the log data to be downloaded and exported to a .CSV file that can then be imported into any industry-standard software or spread sheet for analysis.

► Replaceable Filter Patch (FLT-C001)

The windshield filter of DL-1000 is replaceable and with replaceable patches, which makes it easy for user to replace by themselves. Commercially available sensors are easily affected by dust when used outdoors, which may result in continuous alarm readings and the inability to correctly measure ambient gases. They need to be sent back to the original factory for repair, which increases costs and downtime. ICP DAS’s design allows users to easily replace the filter, reducing maintenance costs and time caused by dust blockage.

DL-10xx_series_en
